This is SkyRC GNSS Performance Analyzer.

Find out the speed before and after modifications.

By knowing the facts before and after modifications, your efforts will not be in vain. For everyone trying to gauge their performance, here's an affordable way to do just that. Just got some new mods installed? Get some real feedback, really quickly. This is a professional-grade instrument accessible to enthusiasts. It’s every modeler’s dream. Enjoy!

Improved accuracy by tracking two satellite constellations

The GNSS Performance Analyzer supports GNSS(Global Navigation Satellite System) with GPS and GLONASS system that means more satellites are orbiting the earth. The advantage of this many satellites will definitely improve positional accuracy by tracking two satellite constellations instead of just GPS.

Small but Versatile

GNSS Performance Analyzer（GSM020) allows you to measure and analyze many aspects of your RC car & airplane’s performance using the latest GNSS engine (GPS, GLONASS) which gives you Acceleration, G-force, Speed, Time, Distance, High and Vertical Velocity. With its compact dimension of 40mm x 40mm x 17mm and internal antenna, it is an ideal choice for mounting on RC vehicles & airplanes.

Case Size: 40 x 39 x 16mm Weight: 38g

Peace of mind with built-in liPo battery

The 5 hours' up-time on the built-in rechargeable LiPo battery can give enough racing time to RC drivers or pilots in the field! With the micro USB charging port, it is very convenient to connect it to a USB port or another compatible USB power source for charging.

Go mobile with the app

With the free RC Gears App, drivers can track and monitor driving racing speed and remotely from the Android or iOS device. iOS 9.0 or above / Android 8.0 or above, to download app, CLICK HERE.

Drag Race: The RC Gears App software automatically charts slope on as time elapses. Saved runs can be read by the App, allowing analyzing of average speed, maximum speed, and acceleration within the given time and defined distance. You can also define your own performance windows for measuring braking time, acceleration (e.g., 0-30 km/h, 10-50 km/h, 10 meters or any custom setting), G-force measurement, Max Speed, Average Speed, Distance, High and Vertical Velocity.
Track Race: The meter can also be used as a speedometer and provides accurate logging of speed data.
Flying Mode: The meter measures average speed, maximum speed, time elapsed, distance and altitude.
Rocket Mode: The rocketry is heating up again as the battle of the space billionaires is going: Elon Musk, Richard Branson and Jeff Bezos are clamoring to reach space. As a rocket hobbyist, you can not rule out someday we will colonize by rocket. The model rocket is the best choice to prototype for that day. Rocket mode in the app acts as a flight altitude meter on your smartphone or tablet. Simply tap a button to start recording the altitude and acceleration of your model rocket. Data is downloaded directly to your smart device after the flight. Through the app, you can view, annotate, and share your flights.

Visual LED indicator

The GNSS Analyzer is equipped with 3 LED indicators, signaling different operating modes. Open RC Gears on the smartphone, the analyzer’s Bluetooth icon will stay steady blue, reflecting the device is connected; the satellite icon will stay steady green after a while of successful GNSS signal acquisition.

Built-in 1M Memory

The built-in 1M memory can record up to 50 records. And all the data can be transferred to the smartphone for analyzing! When the Flash is full, the previous record will be replaced automatically. Now you don't have to think about clearing data all the time or worry about missing the critical tracking data when the memory is full.

Support both Metric and Imperial system of Measurement

The Metric and Imperial systems can be switched easily by the App!
